MODEL NO :
SR650
SR 950
SR1000
|
Generator |
Model no |
SR650 |
SR950 |
SR1000 |
|
Frequency (Hz) |
50/60 |
50/60 |
50/60 |
|
Max. Power (w) |
550 |
800 |
900 |
|
Rated Power (w) |
450 |
650 |
750 |
|
Voltage (v) |
220 |
220 |
220 |
|
Rated Current (A) |
2 |
3 |
3.4 |
|
Engine |
Run Time (Hrs) |
8 |
5.8 |
5 |
|
Fuel |
Gasoline :two-stroke ludricant =50:1 |
|
Fuel Tank (L) |
4 |
|
|
|
Displacement |
63cc |
|
Package |
Noise Level (at 7m) |
63db |
64db |
64db |
|
Engine Type |
2-stroke, Air-cooled |
|
Dimension (cm) |
L39XW33XH33 |
|
N. W/G. W. (kg) |
18/20 |
20/22 |
21/33 |
|
20¨FCL (pcs) |
740 |
|
|
40¨FCL(PCS) |
1480 |
Gasoline
generator sets adopt different diesel engines and brushless
generators. Generally adopt 4-stroke OHV engine(SR950 series
adopts 2 stroke engine), low fuel consumption, high
reliability; It is easy to maintain as adopting brushless a.
C. Generator and CDI ignition system. If fitted with large
capacity of fuel tank, can run for 12hours; Also charge for
battery with 12V DC. The types of generator sets are
quick-starting, stable-running, little vibration, low noise,
light weight, small volume, compact structure, suitable for
areas on mining, factory, working on field, engaging in
construction and army as movable power or electric power in
ship, also suitable for areas on animal husbandry, fishery,
forest, orchard, guesthouse and business as standby power.
|
